U2P2DC US Motors General Purpose Motor 2 HP - TEFC - 1750 RPM
This us motors general purpose motor 2 hp tefc 1750 rpm from US MOTORS is designed to deliver reliable performance and durability.
Key Features
- Designed to match or exceed applicable specifications
- Provides the function required for the intended system or assembly
- Built for dependable performance and service life
- Backed by US MOTORS quality and engineering.
Specifications
| Brand | US MOTORS |
| Part Type | US Motors General Purpose Motor 2 HP TEFC 1750 RPM |
| SKU | U2P2DC |
| OEM Cross Reference | 704338AT Specifications: Manufacturer US MotorsFamily Series US Motors MotorsType General PurposeHorsepower 2 hpKilowatts 1.5 kWRPM 1, 750 RPMNumber of Poles 4Phase 3NEMA Frame 145TCVoltage (AC) 208-230 VAC, 460 VACNominal Voltage 208 VAC, 240 VAC, 480 VACEnclosure Totally Enclosed Fan CooledMounting Type C-Face FootedFull Load Current 5.9-5.7 A, AComposition Rolled SteelModel Number FD15Net Weight 2.1875 lbsGross Weight 43 lbs |
| UPC | 704338AT |
| Weight | 43.0 lb |
Brand Information
Brand: US MOTORS
US MOTORS supplies quality parts and components designed to provide dependable performance and long service life in their intended applications.
Installation Notes
- Verify part number, specifications, and application before installation.
- Professional installation is recommended.
